VOLTAGE REGULATOR/RECTIFIER 12VOLT 5 POLE LATER SINGLE YELLOW WIRE - VNX/VSX/STELLA/PX MOST BIKES WITH A BATTERY (185824 82587R 58096R)
Brand | Vintage Vespa Item |
---|---|
Description | VOLTAGE REGULATOR/RECTIFIER 12 VOLT 5 POLE LATER SINGLE YELLOW WIRE - VNX/VSX/STELLA/PX MOST BIKES WITH A BATTERY (185824 82587R 58096R) AC/DC Regulator/Rectifier 12V 5 Pole. This regulator has two function: 1) A shunt regulator for the AC power from the stator to the headlight & 2) A rectifier/regulator to charges the 12 volt battery for the horn, and other circuits powered by the DC 12v Battery. This regulator essentially has two isolated regulators one for AC and the other for DC charging of the battery. Functions of the terminals on this voltage regulator are:
Wiring tips for Stella & LML 2t & 4t scooters:
With a fully charged 12 volt battery, the battery voltage will read between 12.6 and 13 volts when the engine runs and with a fully charged. The DC charging voltage is very low on the Stella electric start, the Battery only powers intermittent DC 12 volt loads such as the horn, turn signals and electric starter. Tail light and headlight are powered by the AC coils when the engine is running. We recommend the use of a Battery Tender style battery maintainer when the scooter is not used to keep the battery charge topped off. Stella scooters make use of a Switching Module #C-4727388 to switch on the DC loads like the tail light once the scooter starts and AC power is generated from the stator plate. Fits the following models: Late 1979-1981 US Market P125X and P200E This later electrical system can be identified by inspecting the wiring junction box at the rear of the motor for 1 Yellow and 1 Red wire. P200E VIN NUMBER VSX1T34628 AND NEWER 2005 PX150 (model officially imported to the USA and Canada). VLX Early 2000’s Genuine Stella 2 stroke and 4 stroke scooters made by LML in India. Some modifications to the wiring are needed (Will not fit Stella Automatic) European Vespa ET4 125cc from 1996-2004 Electrical items have no warranty and are NOT returnable. |
